Satellite and Voice Module

FOB Price: 360 USD

"The GSP-1720 offers satellite data and voice module using the Globalstar service. It enables voice capability and full two-way data, allowing the development of new and creative tracking and control & monitor applications to full-featured fixed telephone service for remote areas. The GSP-1720 satellite data and voice module enables full two-way data and voice capability, allowing the development of new and creative tracking and monitor & control applications to full-featured fixed telephone service for remote areas. For Supervisory Control and Data Acquisition (SCADA) applications, the GSP-1720 Satellite Data/Voice Module (SDVM) can provide either Direct or Dial-up Internet as well as asynchronous computer to computer connectivity. These options provide communications with land and marine-based equipment, while complementing mobile and stationary field solutions. Mobile or stationary, the GSP-1720 helps you monitor, control or track assets remotely through the Globalstar satellite network - affordably and with low-power requirements. Designed for multiple applications, the GSP-1720 Module offers a flexible solution for the Original Equipment Manufacturer (OEM), as well as providing a developer's kit for accelerated time to market. The Globalstar GSP-1720 comes with: The Satellite Data Voice Module (SDVM) OEM board"

Brand: Globalstar

Place of Origin: United Kingdom

Certification:

Grade:

Minimum Order Quantity: 1

Seller: Global Telesat Communications

View Seller Profile
Contact this Seller to buy this product

Specifications

Logistic Details

Payment Options

Seller Details

Operating Frequency
Transmit: 1610 - 1625 MHz
Receive: 2484-2499 MHz

Maximum Transmit Power
Passive antenna: +26 dBm (400 mW)
Active antenna: +29 dBm (800 mW)

DC Input Voltage +4.7 V to +5.1 V (7.0 V optional for active antenna)

Interfaces
User Ports 22 pin Molex connector with pin-outs for data port, auxillary port (control/NEMA), audio and power.
USB-B connector for data and diagnostics connectivity.

Module Antenna Connectors: TX SMA female, RX SMA Male

Antenna Connectors:
Passive: TX SMA Female, RX SMA Female
Active: TX SMA male, RX SMA female, Diagnostic Monitor and Software Upgrade USB-B Connector

Module Dimensions: 119 mm x 65 mm x 15 mm
Module Weight: less than 60g
Certification: FCC, ETSI, IC
Module Environmental Conditions Operating: -22 to +140ºF (-30 to +60ºC)
Storage: -40 to +185ºF (-40 to +85ºC)

Key Feature:

Globalstar Satellite Data Service
Globalstar Satellite Voice Service
Direct Internet or Direct Dial-up Circuit Switched Data
9.6 kbps full duplex service (express data available up to 19 kbps)
Utilizes standard and enhanced “Hayes Modem” AT commands
Compatible with Windows 98/2000/XP/NT/ME/Vista
Dial-up networking, Asynchronous data communications static IP
Short Messaging Service (SMS): 35 character incoming
Crystal clear voice quality: Superior CDMA digital satellite quality
Automatic system select: Just apply power to the unit and your Globalstar module will automatically seek out the Globalstar network.

Processing Time: 2 - 4 weeks
Port: Liverpool
Supplier Ability: On Demand
Packing Details: As per customer requests

TT LC DP Money Gram WesternUnion Other

Seller: Global Telesat Communications [View Seller Profile]

Verified Seller

** This is a Gold Seller. This means we trust this Seller a lot ! **

Country: United Kingdom
